Parker ACR Series User Manual

Parker Hannifin
ACR9040 Controller Accessories
1
Description Part Number
Drive Cables
2
EPL controller to drive Ethernet cable, SFTP 71-028656-xx
Communications Cable
Standard cable for RS-232 operation, 10 ft (3,048 mm)
(COM1 port 9-pin to PC 9-pin, D-sub connectors)
71-016939-10
Ethernet crossover cable, 5 ft (1524 mm), unshielded CAT 5E 71-017635-01
Expansion I/O
25-pin D-sub to screw terminal breakout board with 2 ft cable VM25
Expansion I/O cable 71-022338-xx
3
PIO 337, Buscoupler, CANopen STD 01-022317-01
PIO 347, Buscoupler, CANopen ECO 01-022318-01
PIO 400, Input, 2-channel, 24 VDC, 3.0 ms 01-022325-01
PIO 402, Input, 4-channel, 24 VDC, 3.0 ms 01-022324-01
PIO 430, Input, 8-channel, 24 VDC, 3.0 ms 01-022323-01
PIO 468, Input, 4-channel, 0-10 VDC, analog 01-022329-01
PIO 480, Input, 2-channel, 0-20 mA, differential isolated 01-022330-01
PIO 501, Output, 2-channel, 24 VDC, 0.5 A 01-022328-01
PIO 504, Output, 4-channel, 24 VDC, 0.5 A 01-022327-01
PIO 530, Output, 8-channel, 24 VDC, 0.5 A 01-022326-01
PIO 550, Output, 2-channel, 0-10 VDC, analog 01-022331-01
PIO 552, Output, 2-channel, 0-20 mA 01-022332-01
PIO 600, end module 01-022333-01
1. A power cord does not ship with the unit.
2. Each cable comes in a 1-foot (304.8 mm), 3-foot (914.1 mm), 5-foot (1,524mm), 10-foot
(3,048 mm), or 25-foot length (7,620 mm) in the part number -xx (-01, -03, -05, -10, or -
25).
3. The cable comes in a 2-foot (609.6 mm) or 4-foot length (1,219 mm) in the part number
–xx (-02 or -04).
Table 3 ACR9040 Controller Accessories
Chapter 1 Introduction 19
