Touch Screen Navigation
2-30
Oven
The Oven Temperature Program provides fields and a graph that reflect the
current temperature program as shown in the screen on the left below. Pressing
the Go to button invokes a dialog box that allows users to raise the temperature
to a value associated with another step. The last step of the current program is
selected by default. Radio buttons for steps that exceed the number of steps in the
current program are deactivated.
In the example below, step 2 is selected. As soon as the user touches the OK
button the change is implemented. The graph in the capture on the right shows
the immediate temperature rise and the departure from the program.
Graph and status bar show the
oven is ready to run a program.
Touching the Go to button displays
the Go to Temp dialog box to
select a step to go to. In this
example step 2 is selected. Press
the OK button to immediately raise
the oven temperature to the value
specified in step 4.
The blue line in the graph reflects
the departure from the program.
