Clarus 600/680 User’s Guide
3-11
3. Enter a ramp initial rate 1 of 2 °C/min.
4. For Temp 2, enter a temperature of 70 °C.
5. Enter a time of 10 min.
Setting Up a Multiramp Temperature Program
The following example shows how to expand the above one-ramp program to a two-ramp
program. The parameter values used in the example are shown below:
Time 3 5 min
Rate 3 0 °C/min
1. From the oven tab enter a rate of 4.
2. Enter a temperature of 100.
3. Enter a time of 5.
NOTE: You can enter RATE 3, TEMP 4, and TIME 4 to set up a third ramp.
Holding an Oven Temperature
While running a temperature program, you can hold the oven temperature by setting it to
the temperature of the unexecuted steps.
To hold an oven temperature during a temperature program:
1. In the System Status screen touch the oven button
.
