Philips Pathology Scanner SG20 - Technical Data; Dimensions and Weight; Work Bench

Dimensions and weight Technical data
95
4522 207 12671 * 2021-06-17
Pathology Scanner SG20 / SG60 / SG300
Technical data
Dimensions and weight
Definition Specification
SG20 SG60 SG300
Doors closed
Depth (mm) 680 680 680
Width (mm) 800 800 950
Height (mm) 675 675 675
Store door and maintenance door opened
Depth (mm) 1030 1030 1030
Width (mm) 955 955 1130
Height (mm) 675 675 675
Tab. 28: Dimensions of the scanner
Definition Specification
SG20 SG60 SG300
Weight (kg) 142 142 150
Tab. 29: Weight of the scanner
Work bench
The work bench on which the scanner will be placed must meet the requirements listed. The
work bench must be stable in horizontal movement and not be accessible from the bottom
side.
Definition Specification
Size Width: 1200 mm
Depth: 850 mm
Height
1
700 mm
Weight capacity 600 kg
Number of legs 4
Adjustable to correct unevenness of the floor
2
yes
Wheels no
12
