Ricoh Aficio SP C311N User Manual

Replacing Consumables
74
6
Replacing the Waste Toner Bottle
R
WARNING:
R
CAUTION:
❖ When to replace the waste toner bottle
If the Alert indicator on the control panel lights up and the following message
appears on the display, replace the waste toner bottle:
“
Replace Waste Toner”
Important
❒ Waste toner bottles cannot be reused.
❒ Purchasing and storing extra waste toner bottles is recommended.
❒ If the bypass tray is open, close it before pulling out Tray 1.
❒ When removing the waste toner bottle, make sure not to tilt it.
❒ Keep the waste toner bottle horizontal as you take it out.
❒ Make sure that the transfer unit is installed. If the transfer unit is not installed,
install it before turning the power on.
❒ Cooperate with the waste toner bottle Recycling Program, whereby used
waste toner bottles are collected for recycling.
• Do not incinerate spilled toner or used toner. Toner dust might ignite
when exposed to an open flame.
• Wait for 30 minutes or more after disconnecting the power plug before
removing the transfer unit.
• Do not incinerate used toner or toner containers. Toner dust might ig-
nite when exposed to an open flame. Dispose of used toner containers
in accordance with local regulations.
• The inside of this printer becomes very hot. Do not touch parts labelled “v”
(indicating a hot surface).
• Keep toner (used or unused) and toner containers out of reach of children.

Ricoh Aficio SP C311N Specifications

Printing

resolution	600 x 600 dpi (default), 1200 x 600 dpi, 2400 x 600 dpi
printing speed	26 ppm (Letter)
first print speed	13.5 sec. or less

Paper Handling

standard paper capacity	500 sheets
bypass tray capacity	100 sheets
maximum paper capacity	Up to 1, 100 sheets

Power

power source	120V, 60Hz
maximum power consumption	1300W or less
energy saver power consumption	15W or less

Weight and Dimensions

dimensions	15.8" x 15.2" x 18.9" (400 mm x 387 mm x 480 mm)
weight	61.73 lb. (28.0 kg)
