Ricoh Aficio SP C311N User Manual

PS Menu
63
5
PS Menu
You can set conditions when using PostScript for printing.
Changing the PS Menu
Use the following procedure to change the settings for Resolution.
A Press the {Menu} key.
The menu screen appears.
B Press {U} or {T} to display [PS Menu], and then press the {#Enter} key.
C Press {U} or {T} to display [Resolution], and then press the {#Enter} key.
D Press {U} or {T} to select the resolution, and then press the {#Enter} key.
The selected resolution is displayed for two seconds with an asterisk, and
then the [PS Menu] screen appears.
E Press the {Menu} key to return to the initial screen.
PS Menu Parameters
This section explains about parameters that can be set on the PS Menu.
❖ Resolution
You can specify the print resolution in dots per inch.
Default: 600x600 dpi 1bit
• 600x600 dpi 1bit
• 600x600 dpi 2bit
• 600x600 dpi 4bit
❖ Color Profile
You can select the color profile.
Default: Solid Color
•Off
• Solid Color
•Presentation
• Photographic
ASI066S

Ricoh Aficio SP C311N Specifications

Printing

resolution	600 x 600 dpi (default), 1200 x 600 dpi, 2400 x 600 dpi
printing speed	26 ppm (Letter)
first print speed	13.5 sec. or less

Paper Handling

standard paper capacity	500 sheets
bypass tray capacity	100 sheets
maximum paper capacity	Up to 1, 100 sheets

Power

power source	120V, 60Hz
maximum power consumption	1300W or less
energy saver power consumption	15W or less

Weight and Dimensions

dimensions	15.8" x 15.2" x 18.9" (400 mm x 387 mm x 480 mm)
weight	61.73 lb. (28.0 kg)
