Ricoh Aficio SP C311N User Manual

Cleaning the Printer
100
7
Cleaning the Toner Density Sensor
Clean the toner density sensor when the following message appears on the con-
trol panel.
“ Toner Den.Sensor cleaning req. ”
R
CAUTION:
A Pull up Top Cover Open Lever to open the top cover.
B Lift out the cyan print cartridge.
C Slide the toner density sensor lever once to the left.
Slide the lever only once.
• Be careful not to trap your fingers when opening or closing the top cover.
ASH004S
ASH005S
BAA079S

Ricoh Aficio SP C311N Specifications

Printing

resolution	600 x 600 dpi (default), 1200 x 600 dpi, 2400 x 600 dpi
printing speed	26 ppm (Letter)
first print speed	13.5 sec. or less

Paper Handling

standard paper capacity	500 sheets
bypass tray capacity	100 sheets
maximum paper capacity	Up to 1, 100 sheets

Power

power source	120V, 60Hz
maximum power consumption	1300W or less
energy saver power consumption	15W or less

Weight and Dimensions

dimensions	15.8" x 15.2" x 18.9" (400 mm x 387 mm x 480 mm)
weight	61.73 lb. (28.0 kg)
