Ricoh Aficio SP C311N User Manual

Cleaning the Printer
102
7
Cleaning the Friction Pad and the Paper
Feed Roller
If the friction pad or paper feed roller is dirty, a multi-feed or misfeed might oc-
cur. In this case, clean the friction pad and paper feed roller as follows:
R
CAUTION:
Important
❒ Do not use chemical cleaner or organic solvent such as thinner or benzine.
A Turn off the power switch.
B Pull out the plug from the socket. Remove all the cables from the printer.
C Lift and pull Tray 1 carefully, and then pull it out with both hands.
Place the tray on a flat surface. When there is paper in the tray, remove paper.
• Unplug the power cord from the wall outlet before you move the machine.
While moving the machine, you should take care that the power cord will
not be damaged under the machine.
• Do not pull out the paper tray forcefully. If you do, the tray might fall and
cause an injury.
• Do not put your hands inside the printer when the input tray is removed.
Some internal parts become hot and are a burn hazard.
ASI005S

Ricoh Aficio SP C311N Specifications

Printing

resolution	600 x 600 dpi (default), 1200 x 600 dpi, 2400 x 600 dpi
printing speed	26 ppm (Letter)
first print speed	13.5 sec. or less

Paper Handling

standard paper capacity	500 sheets
bypass tray capacity	100 sheets
maximum paper capacity	Up to 1, 100 sheets

Power

power source	120V, 60Hz
maximum power consumption	1300W or less
energy saver power consumption	15W or less

Weight and Dimensions

dimensions	15.8" x 15.2" x 18.9" (400 mm x 387 mm x 480 mm)
weight	61.73 lb. (28.0 kg)
