Configuration
32
4
D Press the {T} or {U} key to display [Frame Type (NW)], and then press the
{#Enter} key.
E Press the {T} or {U} key to select the frame type, and then press the {#Enter}
key.
F Press the {Menu} key.
The initial screen appears.
G Print a configuration page to confirm the settings made.
Reference
For details about printing the configuration page using control panel, see
p.14 “Test Printing”.
Setting the Ethernet Speed
You can set the speed that the printer will use for Ethernet communication. For
normal usage, the default setting [Auto Select] is suitable and does not need to be
changed. This setting allows two connected interfaces to automatically deter-
mine the optimum speed that they will communicate at.
Important
❒ Connection cannot be established if the selected Ethernet speed does not
match your network's transmission speed.
❒ The use of this feature is recommended. To use it, select [Auto Select].
Network Setup:
Frame Type (NW)
Router/HUB Printer
[ 10Mbps Half D. ] [10Mbps Full D.] [ 100Mbps Half D. ] [ 100Mbps Full D. ] [Auto Select]
10Mbps Half
Duplex
———
10Mbps Full
Duplex
————
100Mbps Half
Duplex
—— —
100Mbps Full
Duplex
——— —
auto-negotia-
tion (auto se-
lection)
——

Ricoh Aficio SP C311N Specifications

Printing

resolution	600 x 600 dpi (default), 1200 x 600 dpi, 2400 x 600 dpi
printing speed	26 ppm (Letter)
first print speed	13.5 sec. or less

Paper Handling

standard paper capacity	500 sheets
bypass tray capacity	100 sheets
maximum paper capacity	Up to 1, 100 sheets

Power

power source	120V, 60Hz
maximum power consumption	1300W or less
energy saver power consumption	15W or less

Weight and Dimensions

dimensions	15.8" x 15.2" x 18.9" (400 mm x 387 mm x 480 mm)
weight	61.73 lb. (28.0 kg)
