Ricoh Aficio SP C311N User Manual

Removing Misfed Paper
132
9
When “Remove Misfeed Bypass Tray” Appears
“Remove Misfeed Bypass Tray” appears when a paper jam has occurred in
the bypass tray.
Open the front cover and remove the paper.
A Remove paper loaded in the bypass tray, and then close the bypass tray
with both hands.
B Pull Front Cover Open Lever, and then open the front cover with both
hands carefully.
C Pull out the jammed paper carefully.
ASI059S
ASI025S
ASI060S

Ricoh Aficio SP C311N Specifications

Printing

resolution	600 x 600 dpi (default), 1200 x 600 dpi, 2400 x 600 dpi
printing speed	26 ppm (Letter)
first print speed	13.5 sec. or less

Paper Handling

standard paper capacity	500 sheets
bypass tray capacity	100 sheets
maximum paper capacity	Up to 1, 100 sheets

Power

power source	120V, 60Hz
maximum power consumption	1300W or less
energy saver power consumption	15W or less

Weight and Dimensions

dimensions	15.8" x 15.2" x 18.9" (400 mm x 387 mm x 480 mm)
weight	61.73 lb. (28.0 kg)
