Ricoh Aficio SP C311N User Manual

Using Smart Organizing Monitor
75
6
Note
❒ To automatically display the Smart Organizing Monitor dialog box when errors
occur, in the printer driver's properties dialog box, on the [Advanced Options] tab,
select the [Display Smart Organizing Monitor automatically] check box.
Displaying the Printer Status
In the Smart Organizing Monitor dialog box, you can check the status of moni-
tored printers.
The printer status is displayed using graphics and comments.
1. Printer graphic
If an input tray error occurs, appears.
This identifies the tray where the error
occurred. The problem tray is outlined in
red.
2. Comments
Displays current printer status and in-
structions for resolving problems.
3. [Continue] button
Click to display the [Form Feed] dialog
box which you can use to change input
tray settings.
4. [Cancel] button
Click to cancel a print job.
5. [User Guide] button
Click to display error related Help.
6. [Search Network Printer] button
Click to select a network printer.
7. [User Tools] tab
Prints the test page or configuration
page. The [Printer Configuration] dialog box
can be opened from this tab.
8. [Job Log] tab
Displays the information related to print
jobs.
9. [Status] tab
Display the status of the items such as
toner levels and paper level.
Note
❒ [Continue] and [Cancel] button are always disabled for this printer model.
ASI201S

Ricoh Aficio SP C311N Specifications

Printing

resolution	600 x 600 dpi (default), 1200 x 600 dpi, 2400 x 600 dpi
printing speed	26 ppm (Letter)
first print speed	13.5 sec. or less

Paper Handling

standard paper capacity	500 sheets
bypass tray capacity	100 sheets
maximum paper capacity	Up to 1, 100 sheets

Power

power source	120V, 60Hz
maximum power consumption	1300W or less
energy saver power consumption	15W or less

Weight and Dimensions

dimensions	15.8" x 15.2" x 18.9" (400 mm x 387 mm x 480 mm)
weight	61.73 lb. (28.0 kg)
