Ricoh Aficio SP C311N User Manual

Troubleshooting
114
8
When the Printer is Directly Connected to a Computer via USB
Cable
Windows
When the printer is directly connected via a USB cable to a computer but the
Ready indicator does not flash or light up, use the following method to check the
port connection:
• For a USB port connection, port USB00 (n)
*1
should be set.
*1
(n) is the number of printers connected.
Windows 2000
A Click [Start], point to [Settings] and then click [Printers].
B Click to select the icon of the printer. Next, on the [File] menu, click [Proper-
ties].
C Click the [Port] tab.
D Check the [Print to the following port] box to confirm that the correct port is se-
lected.
If the port (such as LPT1) is not correct, reinstall the driver.
Reference
For details about installation and port settings, see Software Guide.
Windows XP Professional, and Windows Server 2003/2003 R2
A Access the [Printers and Faxes] window from [Start] on the taskbar.
B Click to select the icon of the printer. Next, on the [File] menu, click [Proper-
ties].
C Click the [Port] tab.
D Check the [Print to the following port(s).] box to confirm that the correct port is
selected.
If the port (such as LPT1) is not correct, reinstall the driver.
Reference
For details about installation and port settings, see Software Guide.

Ricoh Aficio SP C311N Specifications

Printing

resolution	600 x 600 dpi (default), 1200 x 600 dpi, 2400 x 600 dpi
printing speed	26 ppm (Letter)
first print speed	13.5 sec. or less

Paper Handling

standard paper capacity	500 sheets
bypass tray capacity	100 sheets
maximum paper capacity	Up to 1, 100 sheets

Power

power source	120V, 60Hz
maximum power consumption	1300W or less
energy saver power consumption	15W or less

Weight and Dimensions

dimensions	15.8" x 15.2" x 18.9" (400 mm x 387 mm x 480 mm)
weight	61.73 lb. (28.0 kg)
