Ricoh Aficio SP C311N User Manual

Special Operations under Windows
92
8
Using a Host Name Instead of an IPv4 Address
When a host name is defined, you can specify a printer by host name instead of
IPv4 address. The host names vary depending on the network environment.
When using DNS
Use the host name set to the data file on the DNS server.
When setting the IPv4 address of a printer using DHCP
Use the printer name on the configuration page as the host name.
Reference
For details about printing a configuration page, see p.77 “Printing the printer
configurations”.
In other cases
Add the IPv4 address and host name of the network printer to the hosts file on
the computer used for printing.
A Open the hosts file using memo pad files, for instance.
The hosts file is in the following folder:
\WINNT\SYSTEM32\DRIVERS\ETC\HOSTS
B Add an IPv4 address and host name to the hosts file using the following
format:
192.168.15.16 host# NP
“192.168.15.16” is the IPv4 address, “host” is this printer's host name, and
“#NP” is replaced by comments. Insert a space or tab between “192.168.15.16”
and “host”, between “host” and “#NP” respectively, using one line for this
format.
C Save the file.

Ricoh Aficio SP C311N Specifications

Printing

resolution	600 x 600 dpi (default), 1200 x 600 dpi, 2400 x 600 dpi
printing speed	26 ppm (Letter)
first print speed	13.5 sec. or less

Paper Handling

standard paper capacity	500 sheets
bypass tray capacity	100 sheets
maximum paper capacity	Up to 1, 100 sheets

Power

power source	120V, 60Hz
maximum power consumption	1300W or less
energy saver power consumption	15W or less

Weight and Dimensions

dimensions	15.8" x 15.2" x 18.9" (400 mm x 387 mm x 480 mm)
weight	61.73 lb. (28.0 kg)
