Ricoh Aficio SP C311N User Manual

135
10. Appendix
Moving and Transporting the Printer
R
CAUTION:
Repack the printer in its original packing materials for transporting.
Important
❒ Be sure to disconnect all cables from the printer before transporting it.
❒ The printer is a precision piece of machinery. Be sure to handle it carefully
when moving it.
❒ If the optional paper feed unit is installed, remove it from the printer, and
then move them separately.
❒ Do not grip on the tray area when lifting the printer.
Note
❒ The printer weighs approximately 28 kg (61.7 lb.).
• The printer weighs approximately 28 kg (61.7 lb.). When moving the printer,
use the inset grips on both sides, and lift slowly in pairs. The printer will
break or cause injury if dropped.
• Unplug the power cord from the wall outlet before you move the machine.
While moving the machine, you should take care that the power cord will
not be damaged under the machine.
• When you disconnect the power plug from the wall outlet, always pull the
plug (not the cable).
• When moving the printer after use, do not take out any of the toners, nor
the waste toner bottle to prevent toner spill inside the machine.

Ricoh Aficio SP C311N Specifications

Printing

resolution	600 x 600 dpi (default), 1200 x 600 dpi, 2400 x 600 dpi
printing speed	26 ppm (Letter)
first print speed	13.5 sec. or less

Paper Handling

standard paper capacity	500 sheets
bypass tray capacity	100 sheets
maximum paper capacity	Up to 1, 100 sheets

Power

power source	120V, 60Hz
maximum power consumption	1300W or less
energy saver power consumption	15W or less

Weight and Dimensions

dimensions	15.8" x 15.2" x 18.9" (400 mm x 387 mm x 480 mm)
weight	61.73 lb. (28.0 kg)
