Ricoh Aficio SP C311N User Manual

Making Printer Settings Using the Control Panel
50
5
Maintenance Menu
You can set print conditions such as color registration and print starting position.
Adjusting the Color Registration
After moving the printer, printing on thick paper, or printing repeatedly for
some time, color degradation may occur. By performing color registration ad-
justment, you can restore optimum print quality.
If documents show color degradation after the printer is moved, perform auto-
matic color adjustment.
A Press the {Menu} key.
The menu screen appears.
B Press {U} or {T} to display [Maintenance], and then press the {#Enter} key.
C Press {U} or {T} to display [Color Dens/Reg], and then press the {#Enter} key.
D On the confirmation screen, press the {#Enter} key.
Automatic color adjustment begins.
A confirmation message appears when complete.
E Press the {Menu} key to return to the initial screen.
ASI066S

Ricoh Aficio SP C311N Specifications

Printing

resolution	600 x 600 dpi (default), 1200 x 600 dpi, 2400 x 600 dpi
printing speed	26 ppm (Letter)
first print speed	13.5 sec. or less

Paper Handling

standard paper capacity	500 sheets
bypass tray capacity	100 sheets
maximum paper capacity	Up to 1, 100 sheets

Power

power source	120V, 60Hz
maximum power consumption	1300W or less
energy saver power consumption	15W or less

Weight and Dimensions

dimensions	15.8" x 15.2" x 18.9" (400 mm x 387 mm x 480 mm)
weight	61.73 lb. (28.0 kg)
