Ricoh Aficio SP C311N User Manual

Using Web Image Monitor
69
6
Access in the Administrator Mode
Use the following procedure to access Web Image Monitor in the administrator mode.
Note
❒ When you access Web Image Monitor in the administrator mode, "Adminis-
trator" appears under [Logout].
Log on
A On Top Page, click [Login].
The dialog box for entering the user name and password appears.
B Enter the user name and password, and then click [OK].
Note
❒ For details about the login user name and password, consult your network
administrator.
Log off
Click [Logout] to log off.
Note
❒ When log on and made the settings, always click [Logout].
Configuring the Printer Settings
From the [Configuration] page, two menus are available to configure the settings.
Important
❒ To make printer settings, you must access Web Image Monitor in administra-
tor mode. If you access Web Image Monitor in user mode, you can view the
printer settings, but you cannot change them.
❖ Paper
Displays the [Paper] page.
On the [Paper] page, following operations are possible:
• Setting the paper size and type on each tray
• Changing the tray priority
• Printing lists of configuration of the printer

Ricoh Aficio SP C311N Specifications

Printing

resolution	600 x 600 dpi (default), 1200 x 600 dpi, 2400 x 600 dpi
printing speed	26 ppm (Letter)
first print speed	13.5 sec. or less

Paper Handling

standard paper capacity	500 sheets
bypass tray capacity	100 sheets
maximum paper capacity	Up to 1, 100 sheets

Power

power source	120V, 60Hz
maximum power consumption	1300W or less
energy saver power consumption	15W or less

Weight and Dimensions

dimensions	15.8" x 15.2" x 18.9" (400 mm x 387 mm x 480 mm)
weight	61.73 lb. (28.0 kg)
