Ricoh Aficio SP C311N User Manual

PCL Menu
61
5
PCL Menu
You can set conditions when using PCL for printing.
Changing the PCL Menu
Use the following procedure to change the settings for Orientation.
A Press the {Menu} key.
The menu screen appears.
B Press {U} or {T} to display [PCL Menu], and then press the {#Enter} key.
C Press {U} or {T} to display [Orientation], and then press the {#Enter} key.
D Press {U} or {T} to select the orientation, and then press the {#Enter} key.
The selected orientation is displayed for two seconds with an asterisk, and
then the [PCL Menu] screen appears.
E Press the {Menu} key to return to the initial screen.
PCL Menu Parameters
This section explains about parameters that can be set on the PCL Menu.
❖ Orientation
You can select the page orientation.
Default: Portrait
•Portrait
•Landscape
❖ Form Lines
You can specify the number of lines per page between 5 and 128.
Default: 64, 60
❖ Font Number
You can specify the ID of the default font you want to use.
Default: 0
ASI066S

Ricoh Aficio SP C311N Specifications

Printing

resolution	600 x 600 dpi (default), 1200 x 600 dpi, 2400 x 600 dpi
printing speed	26 ppm (Letter)
first print speed	13.5 sec. or less

Paper Handling

standard paper capacity	500 sheets
bypass tray capacity	100 sheets
maximum paper capacity	Up to 1, 100 sheets

Power

power source	120V, 60Hz
maximum power consumption	1300W or less
energy saver power consumption	15W or less

Weight and Dimensions

dimensions	15.8" x 15.2" x 18.9" (400 mm x 387 mm x 480 mm)
weight	61.73 lb. (28.0 kg)
