Ricoh Aficio SP C311N User Manual

USB Connection
23
3
USB Connection
Important
❒ USB2.0 interface cable is not supplied. Obtain it separately, according to the
computer you are using.
❒ USB connection is possible under Windows 2000/XP/Vista, Windows Server
2003/2003 R2/2008, and Mac OS X.
❒ USB connection with Macintosh is only possible via the printer's USB port.
A Remove the cable cover.
B Connect the square-shaped connector of the USB2.0 cable to the USB port.
C Connect the opposite end's flat connector to devices such as your compu-
ter's USB interface.
ASI081S
ASH053S

Ricoh Aficio SP C311N Specifications

Printing

resolution	600 x 600 dpi (default), 1200 x 600 dpi, 2400 x 600 dpi
printing speed	26 ppm (Letter)
first print speed	13.5 sec. or less

Paper Handling

standard paper capacity	500 sheets
bypass tray capacity	100 sheets
maximum paper capacity	Up to 1, 100 sheets

Power

power source	120V, 60Hz
maximum power consumption	1300W or less
energy saver power consumption	15W or less

Weight and Dimensions

dimensions	15.8" x 15.2" x 18.9" (400 mm x 387 mm x 480 mm)
weight	61.73 lb. (28.0 kg)
