Ricoh Aficio SP C311N User Manual

29
3. Other Print Operations
Form Feed
Use the form feed function to continue printing when a paper size or paper type
error occurred.
This function can be performed using the control panel.
Important
❒ The tray cannot be changed if the following function is set:
•Cover Sheet
Performing Form Feed
Use the following procedure to perform form feed.
A While an error message is displayed on the control panel, press the
{Stop/Start} key.
B Press {U} or {T} to select the tray, and then press the {#Enter} key.
Printing begins on paper from the selected tray.
Note
❒ If you want to print after adding paper to the tray, load the correct paper,
and then press the {Stop/Start} key.
❒ If a tray with a smaller paper size is selected, the print job may be cut short,
or other problems may occur.

Ricoh Aficio SP C311N Specifications

Printing

resolution	600 x 600 dpi (default), 1200 x 600 dpi, 2400 x 600 dpi
printing speed	26 ppm (Letter)
first print speed	13.5 sec. or less

Paper Handling

standard paper capacity	500 sheets
bypass tray capacity	100 sheets
maximum paper capacity	Up to 1, 100 sheets

Power

power source	120V, 60Hz
maximum power consumption	1300W or less
energy saver power consumption	15W or less

Weight and Dimensions

dimensions	15.8" x 15.2" x 18.9" (400 mm x 387 mm x 480 mm)
weight	61.73 lb. (28.0 kg)
