Ricoh Aficio SP C311N User Manual

Direct Printing from a Digital Camera (PictBridge)
40
4
Exiting PictBridge
Use the following procedure to quit the PictBridge mode.
Important
❒ Do not disconnect the USB cable while data is being sent to the printer. If you
do, printing will fail.
A Check the printer's Ready indicator is lit.
B Disconnect the USB cable from the printer.

Ricoh Aficio SP C311N Specifications

Printing

resolution	600 x 600 dpi (default), 1200 x 600 dpi, 2400 x 600 dpi
printing speed	26 ppm (Letter)
first print speed	13.5 sec. or less

Paper Handling

standard paper capacity	500 sheets
bypass tray capacity	100 sheets
maximum paper capacity	Up to 1, 100 sheets

Power

power source	120V, 60Hz
maximum power consumption	1300W or less
energy saver power consumption	15W or less

Weight and Dimensions

dimensions	15.8" x 15.2" x 18.9" (400 mm x 387 mm x 480 mm)
weight	61.73 lb. (28.0 kg)
