Ricoh Aficio SP C311N User Manual

Installing the Printer and Options
14
2
Test Printing
The following explains the procedure for performing a test print.
Perform the test print to verify the printer is working normally. Test printing
checks printer performance only; it does not test the connection to the computer.
A Press the {Menu} key.
B Press the {T} or {U} key to display [List/Test Print], and then press the {#En-
ter} key.
C Press the {T} or {U} key to display [Config. Page], and then press the {#Enter}
key.
The configuration page will be printed.
D Press the {Menu} key to return to the initial screen.
The initial screen appears.
Note
❒ If printing is not normal, check to see if an error message appears on the
display.
❒ If there is an error message, see p.109 “Error & Status Messages on the Con-
trol Panel”.
Menu:
List/Test Print
List/Test Print:
Config. Page

Ricoh Aficio SP C311N Specifications

Printing

resolution	600 x 600 dpi (default), 1200 x 600 dpi, 2400 x 600 dpi
printing speed	26 ppm (Letter)
first print speed	13.5 sec. or less

Paper Handling

standard paper capacity	500 sheets
bypass tray capacity	100 sheets
maximum paper capacity	Up to 1, 100 sheets

Power

power source	120V, 60Hz
maximum power consumption	1300W or less
energy saver power consumption	15W or less

Weight and Dimensions

dimensions	15.8" x 15.2" x 18.9" (400 mm x 387 mm x 480 mm)
weight	61.73 lb. (28.0 kg)
