Ricoh Aficio SP C311N User Manual

Loading Paper
45
5
Loading Paper
This describes how to load paper into the paper tray and bypass tray.
R
WARNING:
R
CAUTION:
Loading Paper in Tray 1
The following example explains the loading procedure for the standard paper
tray (Tray 1).
Important
❒ Make sure paper is not stacked above the limit mark inside the tray. Misfeeds
might occur.
❒ After loading paper in the tray, specify the paper type and size using the con-
trol panel.
❒ Do not mix different types of paper in the same paper tray.
❒ If the bypass tray is open, close it before pulling out Tray 1.
❒ Do not move the side paper guides forcefully. Doing so can damage the tray.
❒ Do not move the end paper guide forcefully. Doing so can damage the tray.
❒ When inserting the tray, make sure it is not slanted. Inserting it at a slant can
damage the printer.
❒ Curled paper may jam, straighten curled paper before loading.
A Lift and pull Tray 1 carefully, and then pull it out with both hands.
Place the tray on a flat surface.
• Do not put your hands inside the printer when the input tray is re-
moved. Some internal parts become hot and are a burn hazard.
• Do not pull out the paper tray forcefully. If you do, the tray might fall and
cause an injury.
ASI005S

Ricoh Aficio SP C311N Specifications

Printing

resolution	600 x 600 dpi (default), 1200 x 600 dpi, 2400 x 600 dpi
printing speed	26 ppm (Letter)
first print speed	13.5 sec. or less

Paper Handling

standard paper capacity	500 sheets
bypass tray capacity	100 sheets
maximum paper capacity	Up to 1, 100 sheets

Power

power source	120V, 60Hz
maximum power consumption	1300W or less
energy saver power consumption	15W or less

Weight and Dimensions

dimensions	15.8" x 15.2" x 18.9" (400 mm x 387 mm x 480 mm)
weight	61.73 lb. (28.0 kg)
