Installing the Printer Driver in a Network Environment
5
1
Installing the PostScript 3 Printer Driver
Important
❒ Before installing the PostScript 3 printer driver, obtain the printer's IP address
settings. For details, see p.58 “Changing the Host Interface Menu”.
❒ To install this printer driver, you must have an account that has Manage
Printers permission. Log on as an Administrators or Power Users group
member.
A Close all applications except this manual.
B Insert the CD-ROM into the CD-ROM drive.
The installer starts.
C Select an interface language, and then click [OK].
The default interface language is English.
D Click [PostScript 3 Printer Driver].
The Add Printer Wizard starts.
E Click [Next >].
F Click [Local printer], and then click [Next >].
In a Windows Vista environment, click [Add a local printer].
G Click [Create a new port].
H In the drop-down menu, select [Standard TCP/IP Port], and then click [Next >].
The [Add Standard TCP/IP Printer Port Wizard] dialog box appears.
I Click [Next >].
J Enter the printer's IP address in the [Port Name] box, and then click [Next >].
The IP address you enter here is the address you have checked on the config-
uration page.
In a Windows Vista environment, make the following settings in the dialog
box that appears, and then click [Next >].
A In [Device Type] list, select an item.
You can select [Autodetect], [TCP/IP Device], or [Web Services Device].
B Enter an IP address in the [Hostname or IP address:] box.
C If necessary, enter an port name in the [Port name] box.
K Click [Finish].
L Check that the name of this printer whose driver you want to install is se-
lected, and then click [Next >].

Ricoh Aficio SP C311N Specifications

Printing

resolution	600 x 600 dpi (default), 1200 x 600 dpi, 2400 x 600 dpi
printing speed	26 ppm (Letter)
first print speed	13.5 sec. or less

Paper Handling

standard paper capacity	500 sheets
bypass tray capacity	100 sheets
maximum paper capacity	Up to 1, 100 sheets

Power

power source	120V, 60Hz
maximum power consumption	1300W or less
energy saver power consumption	15W or less

Weight and Dimensions

dimensions	15.8" x 15.2" x 18.9" (400 mm x 387 mm x 480 mm)
weight	61.73 lb. (28.0 kg)
