Ricoh Aficio SP C311N User Manual

Printer Status Notification by E-Mail
83
6
F Set [Auto E-mail Notification] to [On].
G Make the necessary settings:
• Items in the SNMP Setting column: Configure the SMTP server. Check
your mailing environment, and then specify the necessary items. You can
also perform mail authentication for the SMTP server.
H Click [OK].
Note
❒ You can set [Auto E-mail Notification:] to [On] using Smart Organizing Moni-
tor.
Mail Authentication
You can configure mail authentication to prevent illegal use of the mail server.
When mail is sent to the SMTP server, authentication is performed using the
SMTP AUTH protocol by prompting the mail originator to enter the user name
and password.
Use the following procedure to specify SMTP authentication.
A In the menu area, click [Configuration].
B Click [Network] in the [Configuration] page.
C Make the following settings:
• SMTP Authentication: Enable or disable SMTP authentication.
• E-mail Address: Enter the e-mail address.
• SMTP User Name: Enter the user name for SMTP Authentication.
• SMTP Password: Enter the password set for the SMTP User Name.
D Click [OK].
E Click [Logout].
F Quit Web Image Monitor.

Ricoh Aficio SP C311N Specifications

Printing

resolution	600 x 600 dpi (default), 1200 x 600 dpi, 2400 x 600 dpi
printing speed	26 ppm (Letter)
first print speed	13.5 sec. or less

Paper Handling

standard paper capacity	500 sheets
bypass tray capacity	100 sheets
maximum paper capacity	Up to 1, 100 sheets

Power

power source	120V, 60Hz
maximum power consumption	1300W or less
energy saver power consumption	15W or less

Weight and Dimensions

dimensions	15.8" x 15.2" x 18.9" (400 mm x 387 mm x 480 mm)
weight	61.73 lb. (28.0 kg)
