Ricoh Aficio SP C311N User Manual

Setting Up the PPD File
97
9
Setting Up the PPD File
A On the desktop, double-click the hard drive icon.
B Click [Applications], and then open the [Utilities] folder.
C Double-click [Printer Setup Utility].
The [Printer List] dialog box appears.
D Click [Add].
• Mac OS X 10.4 or higher
Click [More Printers...]. Then select the zone from the second pop-up menu.
•Other Mac OS X
Click [AppleTalk] on the first pop-up menu.
If the zone is set, select the zone from the second pop-up menu.
E Select the printer, and then select its manufacturer from the [Printer Model:]
pop-up menu.
Under Mac OS X 10.4 or higher, manufacturer from the [Print Using] pop-up
menu.
A list of printer types appears.
F Select the PPD file for the model you are using, and then click [Add].
G Quit Printer Setup Utility.

Ricoh Aficio SP C311N Specifications

Printing

resolution	600 x 600 dpi (default), 1200 x 600 dpi, 2400 x 600 dpi
printing speed	26 ppm (Letter)
first print speed	13.5 sec. or less

Paper Handling

standard paper capacity	500 sheets
bypass tray capacity	100 sheets
maximum paper capacity	Up to 1, 100 sheets

Power

power source	120V, 60Hz
maximum power consumption	1300W or less
energy saver power consumption	15W or less

Weight and Dimensions

dimensions	15.8" x 15.2" x 18.9" (400 mm x 387 mm x 480 mm)
weight	61.73 lb. (28.0 kg)
