Rockwell Automation Publication 2198-UM001D-EN-P - May 2014 101
Configure and Start the Kinetix 5500 Drive System Chapter 6
Menu Screens
The menu screens provide information about the drive, motor, and fault log.
There are no choices to make or settings to save. Press one of the MENU buttons
to access the menu.
You can use the soft menu items and navigation buttons to
view the information.
Table 51 - Navigating the Menu
MAIN MENU
MOTOR INFO
ESC
DRIVE INFO
Menu/Sub Menu
Selections
Attributes Description Example Values
Drive Info
Catalog number 2198-H008-ERSx
Firmware revision FW REV: 1.1.33
Hardware revision HW REV: 1.1
Serial number SERIAL#xxxxxxxxxxx
Motor Info
Model number MODEL: VPL-B1003C
Serial number SERIAL#: xxxxxxxxxxx
Diagnostics>
Drive Diagnostics
Bus diagnostics
BUS VOLT: 0.0V
BUS CUR: 0.0A
Converter diagnostics
CONV UTIL: 0.7%
CONV TEMP: 31.7C
Inverter diagnostics
INV UTIL: 0.0%
INV TEMP: 31.7C
Shunt utilization SHUNT UTIL: 0.0%
Diagnostics>
Motor Diagnostics
Motor speed SPEED:0.0 RPM
Motor current MTR CUR:0.0A RMS
Motor utilization MTR UTIL:0.0%
Motor temperature MTR TEMP:0.00C
Diagnostics>
Encoder Diagnostics
Serial number SERIAL#xxxxxxxxxxx
Resolution RESOLUTION: 262144
Number of turns NO OF TURNS: 1
Encoder temperature ENC TEMP:33.7C
Supply voltage SUPP VOLT:11.3V
Link quality
The link quality attribute indicates how noisy a communication link is and also indicates
if there is a communication link already established at the drive end. The LINK QUAL
value must always be 100%. Persistent values below 100% indicates a poor feedback
ground connection.
LINK QUAL: 100.0%
Remote signal strength indicator
Similar to Link Quality, RSSI reports the quality of link as seen at the motor end by the
encoder. Maintain the RSSI value between 80 and 100%. Persistent values below 80%
indicates a poor feedback ground connection.
RSSI: 100.0%
Accumulated position errors
This is an aggregated number of errors in the primary position feedback channel of DSL
feedback.
POS ERRORS: 1
Channel position errors
This is an aggregated number of errors on a secondary communication channel of the
DSL feedback.
CHNL ERRORS: 5
Fault Log
Fault text Fault code as listed in Fault Codes
beginning on page 140. FLT S45 - FDBK COMM FL
Fault details The problem as reported in Fault Codes
on page 140.
The number of consecutive missed or corrupted
serial data packets from the intelligent feedback
device has exceeded a factory set limit
Fault help The Possible Solution as reported in Fault Codes
on page 140. Check motor feedback cable and connector
To Next Page
