Chapter 7 Troubleshooting the Kinetix 5500 Drive System
Interpret Status Indicators
Refer to these troubleshooting tables to identify faults, potential causes, and the
appropriate actions to resolve the fault. If the fault persists after attempting to
troubleshoot the system, please contact your Rockwell Automation sales
representative for further assistance.
Display Interface
The LCD display provides fault messages and troubleshooting
information by using the soft menu items and navigation
buttons.
Refer to Understanding the Kinetix 5500 Display
on page 100 for more
information on navigating the LCD display menu.
Use these soft menu items to access the fault log and troubleshooting
information.
Fault Codes
The fault code tables are designed to help you determine the source of the fault or
exception. When a fault condition is detected, the drive performs the appropriate
fault action, the fault is displayed, and the fault is added to a persistent fault log
(along with diagnostics data). The earlier faults have priority to be displayed.
The drive removes the fault text from the display when a Fault Reset service is
sent from the controller and the fault is no longer active. If a fault is still active
following a Fault Reset service, the fault is again posted to the display and written
to the fault log.
The drive maintains a log of the last 25 faults with time stamps and stores the
fault log in persistent memory. However, the fault log cannot be cleared on the
drive.
Press to display the list of active fault codes.
Press to display the fault text (exception code in troubleshooting tables).
Press to display the fault details (the problem in troubleshooting tables).
Press to display the fault help (possible solutions in troubleshooting tables).
