222 Rockwell Automation Publication 2198-UM001D-EN-P - May 2014
Appendix C Sizing Multi-axis Shared-bus Configurations
Energy Calculations
The Kinetix 5500 servo drives have internal shunt resistors for dissipating
excessive energy. In addition, Bulletin 2097 external shunt resistors and Bulletin
2198 capacitor modules are available to increase the shared DC bus capacitance.
Use this table to calculate the total energy absorbing potential (joules) and
determine if a capacitor module or external shunt resistor is needed.
Table 91 - Energy Absorbing Potential
Refer to Motion Analyzer software, version 7.0 or later, for custom shunt sizing.
Kinetix 5500 Drive
Cat. No.
Internal Shunt
(1)
J
External Shunt
kJ
Capacitor Module
(1)
J
Capacitor Module, max
(2)
J
2198-H003-ERSx
427.09 12.51
N/A N/A
2198-H008-ERSx 554.4 554.4
2198-H015-ERSx 549.01 12.521 676.32 676.32
2198-H025-ERSx 575.223 12.549 702.53 957.162
2198-H040-ERSx 601.434 22.647 728.74 983.373
2198-H070-ERSx 1827.01 27.218 1954.3 2208.95
(1) Value assumes the use of one servo drive and one capacitor module.
(2) Value assumes the use of one servo drive and the maximum number of capacitor modules allowed.
