Rockwell Automation Publication 2198-UM001D-EN-P - May 2014 205
Upgrade the Drive Firmware Appendix B
Configure Logix5000 Controller Communication
This procedure assumes that your communication method to the Logix5000
controller is the Ethernet network. It also assumes that your Logix5000 Ethernet
module or controller has already been configured.
For more controller information, refer to Additional Resources
on page 12.
Follow these steps to configure Logix5000 controller communication.
1. Open your RSLinx Classic software.
2. From the Communications menu, choose Configure Drivers.
The Configure Drivers dialog box appears.
3. From the Available Driver Types pull-down menu, choose Ethernet
devices.
4. Click Add New.
The Add New RSLinx Classic Driver dialog box appears.
5. Type the new driver name.
6. Click OK.
The Configure driver dialog box appears.
