104 Rockwell Automation Publication 2198-UM001D-EN-P - May 2014
Chapter 6 Configure and Start the Kinetix 5500 Drive System
Configure the Drive
You can include the drive in your Logix Designer application by adding it to a
configured EtherNet/IP module or controller and adding it under the
I/O configuration tree. After setting network parameters, you can view the drive
status information in Studio 5000 software and use it in your Logix Designer
application.
Set the Network Parameters
You must program network parameters by using the LCD display.
1. From the LCD display, select SETUP>NETWORK and choose between
STATIC IP and DHCP.
The default setting is STATIC IP.
2. If STATIC IP, then press to configure the following parameters:
• IP address
• Gateway
• Subnet mask
Settings are stored in nonvolatile memory. IP addressing can also be changed
through the Module Configuration dialog box in RSLinx® software. Changes to
the IP addressing take effect after power is cycled. The drive is factory
programmed to static IP address of 192.168.1.1.
Refer to Setup Screens
on page 102 for help setting the network parameters.
