8.9 Drive control via Ethernet/IP
Overview
EtherNet/IP is an Ethernet-based 󹪝eldbus. EtherNet/IP is used to transfer cyclic process data as
well as acyclic parameter data.
Function description
Parameter Description
p2030= 10 Fieldbus interface protocol selection: Ethernet/IP
p8924 PN DHCP mode 0: DHCP o󹪜
2: DHCP on, identi󹪝cation based on MAC address
3: DHCP on, identi󹪝cation based on Name of Station
p8925 PN interfaces con󹪝guration 0: No function
1: Reserved
2: Save the con󹪝guration and activate
3: Delete con󹪝guration
p8980 Ethernet/IP pro󹪝le
A change only becomes active after the converter power
supply is switched o󹪜 and switched on again.
0: SINAMICS
1: ODVA AC/DC
p8982 Ethernet/IP ODVA speed scaling
A change only becomes active after the converter power supply is switched o󹪜 and
switched on again.
123: 32
124: 16
125: 8
126: 4
127: 2
128: 1
129: 0.5
130: 0.25
131: 0.125
132: 0.0625
133: 0.03125
Parameter
Settings for Ethernet/IP
Parameter Description Factory setting
p2030 Fieldbus interface protocol selection 0
p8920 PN Name of Station -
p8921[0…3] PN IP Address 0
p8922[0…3] PN Default Gateway 0
p8923[0…3] PN Subnet Mask 0
p8924 PN DHCP mode 0
p8925 Activate PN interface con󹪝guration 0
p8980 EtherNet/IP pro󹪝le 0
p8982 EtherNet/IP ODVA speed scaling 128
Advanced commissioning
8.9Drive control via Ethernet/IP
SINAMICS G120C Converters
238 Operating Instructions, 02/2023, FW V4.7 SP14, A5E34263257B AK
