9.2 Identi󹪝cation & maintenance data (I&M)
I&M data
The converter supports the following identi󹪝cation and maintenance (I&M) data.
I&M data Format Explanation Associated param‐
eters
Example for the
content
I&M0 u8[64] PROFIBUS
u8[54] PROFINET
Converter-speci󹪝c data, read only - See below
I&M1 Visible String [32] Plant/system identi󹪝er p8806[0…31] "ak12-ne.bo2=fu1"
Visible String [22] Location code p8806[32…53] "sc2+or45"
I&M2 Visible String [16] Date p8807[0…15] "2013-01-21 16:15"
I&M3 Visible String [54] Any comment p8808[0…53] -
I&M4 Octet String[54] Check signature to track changes for Safe‐
ty Integrated.
This value can be changed by the user.
The test signature is reset to the value
generated by the machine if p8805 = 0 is
used.
p8809[0…53] Values of r9781[0]
and r9782[0]
When requested, the converter transfers its I&M data to a higher-level control or to a PC/PG
with installed STEP7 or TIAPortal.
I&M0
Designation Format Example for the con‐
tent
Valid for PROFI‐
NET
Valid for PROFI‐
BUS
Manufacturer-speci󹪝c u8[10] 00…00hex --- ✓
MANUFACTURER_ID u16 42dhex (=Siemens) ✓ ✓
ORDER_ID Visible String [20] "6SL3246-0BA22-1FA0" ✓ ✓
SERIAL_NUMBER Visible String [16] "T-R32015957" ✓ ✓
HARDWARE_REVISION u16 0001hex ✓ ✓
SOFTWARE_REVISION char, u8[3] "V" 04.70.19 ✓ ✓
REVISION_COUNTER u16 0000hex ✓ ✓
PROFILE_ID u16 3A00hex ✓ ✓
PROFILE_SPECIFIC_TYPE u16 0000hex ✓ ✓
IM_VERSION u8[2] 01.02 ✓ ✓
IM_SUPPORTED bit[16] 001Ehex ✓ ✓
Alarms, faults and system messages
9.2Identi󹪝cation & maintenance data (I&M)
SINAMICS G120C Converters
Operating Instructions, 02/2023, FW V4.7 SP14, A5E34263257B AK 365
