of the safety functions, are in a position to perform the acceptance test in the correct and
appropriate manner.
Wizard for the acceptance test
The "Startdrive Advanced" commissioning tool (requires an appropriate license) includes a
wizard for the acceptance test of the safety functions integrated in the drive.
"Startdrive Advanced" guides you through the acceptance test, generates the appropriate
traces to analyze the machine response – and generates an acceptance report as Excel 󹪝le.
Further information is provided on the Internet:
Startdrive, system requirements and download (https://
support.industry.siemens.com/cs/ww/en/view/109760844)
Reduced acceptance test after function expansions
A full acceptance test is necessary only after 󹪝rst commissioning. A reduced acceptance test
is su󹪟cient when safety functions are expanded.
Measure Acceptance test
Acceptance test Documentation
Functional expansion of the ma‐
chine (additional drive).
Yes.
Only check the safety
functions of the new
drive.
• Supplement machine overview
• Supplement converter data
• Add function table
• Log the new checksums
• Countersignature
Transfer of converter settings to
other identical machines by means
of series commissioning.
No.
Only check the control
of all of the safety func‐
tions.
• Add machine description
• Check checksums
• Checking the 󹪝rmware versions
8.17 Setpoints
8.17.1 Overview
Overview
The converter receives its main setpoint from the setpoint source. The main setpoint
generally speci󹪝es the motor speed.
Advanced commissioning
8.17Setpoints
SINAMICS G120C Converters
270 Operating Instructions, 02/2023, FW V4.7 SP14, A5E34263257B AK
