3.7 Optional components
Line 󹪝lter
The converter is available with and without an integrated line 󹪝lter. With a line 󹪝lter, the
converter achieves a higher radio interference class.
Converter Line 󹪝lter
Class B (Category C1)
for cable-conducted in‐
terference emission
and Class A (Category
C2) for 󹪝eld-conducted
interference emission
4kHz pulse frequency
Maximum motor cable
length, shielded
Frame size AA 0.55kW…2.2kW 6SL3210‑1KE11‑8U.2,
6SL3210‑1KE12‑3U.2,
6SL3210‑1KE13‑2U.2,
6SL3210‑1KE14‑3U.2,
6SL3210‑1KE15‑8U.2
6SL3203‑0BE17-7BA0 50m
Frame size A 3.0kW…4.0kW 6SL3210‑1KE17‑5U.1,
6SL3210‑1KE18‑8U.1
6SL3203‑0BE17-7BA0
2)
25m
Frame size B 5.5kW…7.5kW 6SL3210‑1KE21‑3U.1,
6SL3210‑1KE21‑7U.1
6SL3203‑0BE21‑8BA0
2)
50m
Frame size C 11kW…18.5kW 6SL3210‑1KE22‑6UX1,
6SL3210‑1KE23‑2UX1,
6SL3210‑1KE23‑8UX1
6SL3203‑0BE23‑8BA0
2)
50m with additional fer‐
rite core
We recommend ferrite
cores from Wurth Elektro‐
nik GmbH, Article num‐
ber 74270095.
2)
Installation also as base component
Table 3-1 Line 󹪝lter as base component for converter FSAA
Converter Class A Class B
Frame size AA 0.55kW…2.2kW 6SL3210‑1KE11‑8U.2,
6SL3210‑1KE12‑3U.2,
6SL3210‑1KE13‑2U.2,
6SL3210‑1KE14‑3U.2,
6SL3210‑1KE15‑8U.2
1)
6SE6400-2FA00-6AD0 6SE6400-2FB00-6AD0
1)
with restrictions for G120C FSAA, 2.2kW. See below.
Additional information on line 󹪝lter as base component for converter FSAA is available on the
internet at:
Compatible MICROMASTER 4 options (https://support.industry.siemens.com/cs/us/en/
view/109741027)
Line reactor
The line reactor increases the level of protection for the converter against overvoltages,
harmonics and commutation dips.
Description
3.7Optional components
SINAMICS G120C Converters
34 Operating Instructions, 02/2023, FW V4.7 SP14, A5E34263257B AK
