11.11.4 Sine-wave 󹪝lter
Preconditions for using a sine-wave 󹪝lter:
• Maximum permissible output frequency of the converter: 150Hz
• Converter pulse frequency: 4kHz
The assignment of a suitable sine-wave 󹪝lter to the converter is provided in the following
Chapter:
Optional components (Page34)
Dimensions and mounting dimensions:
Mounting base components (Page46)
Table 11-23 Technical data of the sine-wave 󹪝lter as footprint component
Article no. 6SE6400-3TD00-4AD0 
Power loss at 50/60 Hz 25W 
Degree of protection IP20 
Weight 0.8kg 
Technical data
11.11Accessories
SINAMICS G120C Converters
444 Operating Instructions, 02/2023, FW V4.7 SP14, A5E34263257B AK
