MultiLevel Instruction Manual Parameter List
16.2. Compartments
No. Name K Factory
Setting
Meaning
3.1.3.nn.1 Sensors
3.1.3.nn.1.1 Level Sensor No E Comp.-No. Assignment of compartment no. => level sensor
3.1.3.nn.1.2 Temp. Sensor No. E Comp.-No. Assignment of compartment no. => temp. sensor
3.1.3.nn.1.3 Wet leg Sensor No. E Comp.-No. Assignment of compartment no. => wet leg sensor
3.1.3.nn.1.4 Level Serial No. E Serial number of the connected level sensor
3.1.3.nn.1.5 Wet leg Sensor 2 E N + Comp.-No. Assignment of compartment no. => wet leg sensor 2
3.1.3.nn.1.6 Foot valve E Comp.-No. Assignment of compartment no. => foot valve
3.1.3.nn.1.7 In-line valve E N + Comp.-No. Assignment of compartment no. => in-line valve
3.1.3.nn.2 Installation
3.1.3.nn.2.1 Zero Level sensor E 0 Zero point of the level sensor
3.1.3.nn.2.2 E 25000
3.1.3.nn.2.3 E 0 Shift of the inclination correction table
3.1.3.nn.2.4 E 0 Float immersion depth
3.1.3.nn.2.5 E 0 Level sensor shift in longitudinal direction
3.1.3.nn.2.6 E 0 Level sensor shift in transverse direction
3.1.3.nn.2.7 E 0.0 Shift of the temperature measurement
3.1.3.nn.3
Data
3.1.3.nn.3.1 Comp. volume E 5000 Volume of the compartment
3.1.3.nn.3.2 Pipe Volume E 0 Volume between foot valve & line valve
(determined automatically during calibration)
3.1.3.nn.3.3 Residual Volume E 0 Volume between start of gauge table & line valve
(determined automatically during calibration)
3.1.3.nn.3.4 Float MIN E 40000
3.1.3.nn.3.5 Float MAX E 1000000
3.1.3.nn.3.6 Correction E 1.0 Correction value for the gauge table
3.1.3.nn.3.7 PreStop Level M 0
0 = OFF
3.1.3.nn.3.8 SlopeStop Level M 0 Fill height at which an inclination stop takes place
0 = OFF
3.1.3.nn.3.9 Max. Switchpoint M 0
(only during loading mode)
0 = OFF, no Loading pre-switching functionality
3.1.3.nn.4 W&M Limits
3.1.3.nn.4.1 Min. Pitch Slope E -3.0° Min. Pitch for residue discharge
3.1.3.nn.4.2 Max. Pitch Slope E +3.0° Max. Pitch for residue discharge
3.1.3.nn.4.3 Min. Roll Slope E -3.0° Min. Roll for residue discharge
3.1.3.nn.4.4 Max. Roll Slope E +3.0° Max. Roll for residue discharge
3.1.3.nn.4.5 Min. Dlv. Volume E 5000 Minimum delivery quantity for calibrated delivery
3.1.3.nn.4.6 Max. Volume Change E 100 Max. Change in volume for compartment monitoring
3.1.3.nn.4.7 E 0
3.1.3.nn.5 Preset
3.1.3.nn.5.1 Preset Correction M 20000
3.1.3.nn.5.2 Default Preset M 5000 Standard preset amount
