ID Description Example
>123456789012345678901<
27 Average product temperature [° Kelvin] >Ave. temp. +74,1 °K<
28 <Flow rate 1234 l/min<
29
30 Mass >Mass 123456 Kg<
31 Average density >Density 123,45 <
32* Compensation YES/NO
33 Reference temperature [° Celsius] <comp. temp 15 °C<
34* Reference temperature [° Fahrenheit]
35* Reference temperature [° Kelvin]
36 Product name >EL Heating oil <
37 >V15 ~12345,7 L <
38 Wet leg sensor status >Wet leg: dry<
39 Residual volume status >Residual vol.: added<
40* Max. Compartment volume (100%) in liters Kammervol. 12345 l
41* Fill height (bar chart display in %)
42 Preset [litres] >Preset 123456 L<
43 Residual volume until preset [litres] >Res. vol. 123456 L<
44 Remaining delivery time >Time left 123 min.<
45 Program version >Vers. 01.00[01.00]EN<
46 Nomix fault >xxxxxxxxxxxxxxxxxxxxx<
47 Status of foot valve >Bottom valve : OPEN<
48 Status of throughput valve >Line valve : CLOSED<
MultiLevel Instruction Manual MENU structure
9.7.1.5. Calibration Restrictions – 315
Additional calibration-relevant parameters are listed here.
*3151 – Seal password
The 8-digit ID (password) for
authorization to change the
calibration-relevant parameters
is set here.
‘12345678’.
9.7.1.5.1. Slopes – 3154
Additional calibration-relevant parameters concerning the angle of inclination that are valid for
the entire vehicle are listed here.
Please refer to the explanations of these four parameters on page "Calibration restrictions".
If exceeded or undershot, an uncalibrated delivery takes place.
