MultiLevel Instruction Manual Parameter List
No. Name K Factory
Settings
Meaning
3.1.4.7.1.1 Column 1 M 36 Page 1 / line 1: Product name
3.1.4.7.1.2 Column 2 M 37 Page 1 / line 2: Compartment VT (volume in liters)
3.1.4.7.1.3 Column 3 M 38 Page 1 / line 3: Wet leg sensor status
3.1.4.7.2.1 Column 1 M 1 Page 2 / line 1: Current roll in °
3.1.4.7.2.2 Column 2 M 2 Page 2 / line 2: Min. permissible roll in °
3.1.4.7.2.3 Column 3 M 3 Page 2 / line 3: Max. permissible roll in °
3.1.4.7.3.1 Column 1 M 6 Page 3 / line 1: Current pitch in °
3.1.4.7.3.2 Column 2 M 7 Page 3 / line 2: Min. permissible pitch in °
3.1.4.7.3.3 Column 3 M 8 Page 3 / line 3: Max. permissible pitch in °
3.1.4.7.4.1 Column 1 M 16 Page 4 / line 1: Current temperature in °C
3.1.4.7.4.2 Column 2 M 19 Page 4 / line 2: Delivered volume VT in liters
3.1.4.7.4.3 Column 3 M 20 Page 4 / line 3: Delivered volume V15 in liters
3.1.4.7.5.1 Column 1 M 23 Page 5 / line 1: CTL
3.1.4.7.5.2 Column 2 M 24 Page 5 / line 2: API table for the product
3.1.4.7.5.3 Column 3 M 31 Page 5 / line 3: Product density in kg/m³
3.1.4.7.6.1 Column 1 M 28
3.1.4.7.6.2 Column 2 M 29
3.1.4.7.6.3 Column 3 M 30 Page 6 / line 3: Delivered mass in kg
3.1.4.7.7.1 Column 1 M 42 Page 7 / line 1: Preset amount in liters (VT or V15)
3.1.4.7.7.2 Column 2 M 43 Page 7 / line 2: Remaining volume until preset in liters
3.1.4.7.7.3 Column 3 M 44 Page 7 / line 3: Remaining time until preset in min.
3.1.4.7.8.1 Column 1 M 46 Page 8 / line 1: Current NOMIX status of the compartment
3.1.4.7.8.2 Column 2 M 36 Page 8 / line 2: Product name
3.1.4.7.8.3 Column 3 M 38 Page 8 / line 3: Wet leg sensor status
16.5. Help Displays
ID Description Example
>123456789012345678901<
0 Blank line
1 Roll (Y) >Roll -0.71 ° <
2 Min. roll (compartment) >C.min.roll -3.00 ° <
3 Max. roll (compartment) >C.max.roll +3.00 ° <
4 Min. roll (total) >Tl.min.roll -5.00 ° <
5 Max. roll (total) >Tl.max.roll +5.00 ° <
6 Pitch (X) >Pitch 2.51 ° <
7 Min. pitch (compartment) >C.min.pitch -3.00 ° <
8 Max. pitch (compartment) >C.max.pitch +3.00 ° <
9 Min. pitch (total) >Tl.min.pitch -5.00 ° <
10 Max. pitch (total) >Tl.max.pitch +5.00 ° <
11 Fill height [mm] >Fillheight 1234.56 mm<
12 Measured value of level sensor (raw data) [mm] >Levelsens. 1234.56 mm<
