9.3.2.2. Gauging Table

Gauging table (sample printout!)

16.05.2011 14:07:38

Device : MultiLevel

------------------------------------------

Version : 1.23[1.27]DE

Sealcounter : 000002

Serial no. : ????????

Comp. no. : - ? -

------------------------------------------

Seal broken!

------------------------------------------

Calibration unit

Device : MultiLevel

Version : 00.16

Serial no. : 1322804

------------------------------------------

Compartment 1 : 194 records

SoftwCRC : E58BDCEE

No. h VT

==========================================

1 39.702 mm 0.000 L

2 43.930 mm 7.821 L

3 52.302 mm 26.128 L

4 60.602 mm 45.305 L

5 69.084 mm 66.190 L

6 77.456 mm 88.896 L

7 86.004 mm 112.484 L

8 94.545 mm 137.907 L

9 103.005 mm 164.167 L

10 111.372 mm 191.310 L

11 119.845 mm 219.593 L

12 128.292 mm 249.778 L

13 136.604 mm 277.024 L

14 144.916 mm 308.725 L

15 153.407 mm 340.459 L

16 162.046 mm 373.463 L

17 170.582 mm 406.530 L

18 178.936 mm 441.030 L

19 187.540 mm 476.860 L

20 195.847 mm 511.342 L

21 204.677 mm 547.593 L

22 213.010 mm 583.858 L

23 221.840 mm 622.231 L

24 230.815 mm 663.044 L

25 239.116 mm 701.611 L

26 247.518 mm 740.229 L

27 256.204 mm 781.047 L

28 264.514 mm 819.420 L

29 272.861 mm 858.126 L

30 281.350 mm 899.140 L

31 289.904 mm 942.141 L

32 298.530 mm 985.400 L

33 307.047 mm 1026.376 L

continued...

MultiLevel ???????? 16.05.11 14:07 -02-

------------------------------------------

34 315.394 mm 1067.434 L

35 324.222 mm 1112.951 L

36 332.753 mm 1156.166 L

37 341.756 mm 1201.689 L

38 350.476 mm 1247.432 L

39 359.180 mm 1290.735 L

40 367.701 mm 1336.421 L

41 376.517 mm 1382.101 L

42 385.109 mm 1427.170 L

43 393.524 mm 1472.182 L

44 402.224 mm 1517.075 L

45 411.193 mm 1564.275 L

46 419.563 mm 1609.181 L

47 428.164 mm 1656.160 L

48 436.525 mm 1700.497 L

49 444.903 mm 1747.005 L

50 453.530 mm 1793.487 L

51 461.928 mm 1840.076 L

52 470.425 mm 1886.553 L

53 478.955 mm 1933.022 L

54 487.504 mm 1980.378 L

55 496.132 mm 2027.724 L

56 504.757 mm 2075.237 L

57 513.218 mm 2122.637 L

58 521.519 mm 2167.868 L

59 530.154 mm 2215.394 L

60 538.689 mm 2262.964 L

61 547.231 mm 2310.421 L

62 555.895 mm 2360.249 L

63 564.393 mm 2407.839 L

64 573.142 mm 2455.316 L

65 581.535 mm 2502.704 L

66 590.342 mm 2552.678 L

67 598.893 mm 2600.412 L

68 607.485 mm 2648.172 L

69 615.878 mm 2695.932 L

70 624.575 mm 2745.987 L

71 633.169 mm 2793.847 L

72 641.725 mm 2841.601 L

73 650.332 mm 2889.110 L

74 658.904 mm 2938.346 L

75 667.269 mm 2985.187 L

76 675.723 mm 3034.531 L

77 684.464 mm 3083.924 L

78 693.019 mm 3131.036 L

79 701.544 mm 3180.317 L

80 710.263 mm 3229.686 L

81 718.802 mm 3276.780 L

82 727.123 mm 3324.042 L

83 735.537 mm 3371.369 L

84 744.054 mm 3418.650 L

85 752.531 mm 3465.801 L

86 761.075 mm 3515.283 L

continued...

MultiLevel ???????? 16.05.11 14:07 -03-

------------------------------------------

87 769.734 mm 3562.553 L

88 778.262 mm 3612.073 L

89 786.850 mm 3659.406 L

90 795.521 mm 3708.864 L

91 803.843 mm 3756.101 L

92 812.435 mm 3803.541 L

93 820.888 mm 3850.936 L

94 829.460 mm 3898.299 L

95 837.986 mm 3947.795 L

96 846.683 mm 3995.283 L

97 855.161 mm 4042.622 L

98 863.585 mm 4090.036 L

99 872.102 mm 4137.532 L

100 881.014 mm 4187.397 L

101 889.835 mm 4234.805 L

102 898.297 mm 4282.450 L

103 906.670 mm 4329.808 L

104 915.496 mm 4377.305 L

105 924.259 mm 4427.216 L

106 932.769 mm 4472.511 L

107 941.166 mm 4520.152 L
