MultiLevel Instruction Manual MENU structure
Display when switched o by Loading pre-switching (page 1)
Compartment 1
- empty
- Foot valve closed
Compartment 2
- Gauge moving
- Foot valve closed
Compartment 3
- Filled
- Foot valve closed
Display when switched o by Loading pre-switching (page 2)
Compartment 1
- empty
- Foot valve closed
Compartment 2
- Gauge moving
- Foot valve closed
Compartment 3
- Filled
- Foot valve closed
9.7.1.3.1.1.4. Compartments 1 – Calibration Limits – 313214
Different compartment-dependent calibration limits are set here:
General information about inclination limits
The parameters for the compartment-
dependent inclination limits are intended
to ensure that no residual volumes remain
in the compartment and in the piping in
the case of an unfavourable inclination
of the vehicle.
To this end, limits are entered for each
compartment. If these limits are exceeded,
no further calibrated delivery takes place.
entire vehicle independent of the
compartment-dependent limits. The aim
here is to avoid larger errors resulting
from inaccuracies inthe measurement
of the inclination.
limits have on a delivery.
To Next Page
