MultiLevel Instruction Manual Description of the Level Gauging System
Pos. Name
13 Distance bushing
12 Protection tube
11 Piping system
10
9 Temperature sensor
8 Discharge connector
7 Filling coupling
6 Foot valve
5 Stop valve
4 Product
3 Float
2 Dip stick
1 Compartment
Note:
implemented in compliance with current material standards. The materials
used are stated on the sales drawings for the parts; drawings to this end
are to be found in the appendix.
ATTENTION:
The choice of materials, particularly with regard to resistance to media and
weldability in combination with other tank materials, is the responsibility of the
weldability of the parts in combination with the tank materials.
5.3. Functional Description
MultiLevel is a system for measuring delivery quantities from a tank truck. In
Figure 4: Tank truck with level sensors
Figure 3: Overview of direct delivery left / left-right
The slope of the piping system may vary and is dependent
on the tank truck construction.
