9.7.1.3.1.1.5. Compartments 1 – Volume Preset – 313215
3132151 – Correction Value
After the delivery, the correction value
for the volume preset is automatically
adjusted. This correction value is
necessary because, after the command
is given to close the valves, a certain
is actually stopped. This after run quantity
can be entered in the correction value,
precision.
3132152 – Standard Preset
Value in liters = 5000
9.7.1.3.2. Compartments monitoring during loading – 31351
A setting is made here as to whether the compartment should be monitored during loading.
9.7.1.3.3. Compartments monitoring during delivery – 31352
A setting is made here as to whether the compartment should be monitored during delivery.
MultiLevel Instruction Manual MENU structure
Description Comment
OFF No compartment monitoring
Without foot valve Level monitoring only
FV only at start Can delay the ‘calming’ of the level,
since air may be in the piping.
Not recommended, unless
expressly desired.
FV only at end Not recommended, unless
expressly desired.
FV at start and end ATTENTION:
If the foot valves are opened again
shortly before printing the receipt,
residual volumes can lead to the wet
leg sensor being wetted!
Not recommended, unless
expressly desired.
Description Comment
OFF No compartment monitoring
Without foot valve Level monitoring only PTB requires this setting
FV only at start Can delay the ‘calming’ of the level,
since air may be in the piping.
Not recommended, unless
expressly desired.
FV only at end ATTENTION:
If the foot valves are opened again
shortly before printing the receipt,
residual volumes can lead to the wet
leg sensor being wetted!
Not recommended, unless
expressly desired.
FV at start and end ATTENTION:
If the foot valves are opened again
shortly before printing the receipt,
residual volumes can lead to the wet
leg sensor being wetted!
Not recommended, unless
expressly desired.
