5. Bend the fastener on the inside of the wheel
(nearest
the tiller) backward and hook it around
the link that is before the one holding the fas-
tener (see B in Photo 6/10).
6. Bend the fastener on the outside of thewheel
(furthest from the tiller) backward and hook it
around the link that is before the one holding
the fastener (see Photo 6/11).
7 Repeat steps 1
through 6 to attach the chains
for the other wheel.
(Photo 6/10)
Fasten chain tightly (tiller side).
NOTE: If you would like you chains tighter,
first run the tiller for ten or fifteen minutes un-
til the chains properly locate themselves on
the wheel. Then remove the fasteners and put
them through the second link from the end of
the chain. Then, repeat steps 5 and 6 (above).
ORDERING CHAINS
On your tiller and all tillers with serial num-
bers 31456 and up which have 4:80/4:00 x 8"
tires, be sure you order 8" chains.
(Photo 6/11) Fasten chain tightly on outside.
DOZER/SNOW BLADE AND BUMPER ATTACHMENT BRACKET
Add year-round versatility to your Troy-Bilt
Tiller and even get an extra bonus-because
the attachment bracket also performs as a pro-
tective Bumper!
The Dozer/Snow Blade gives your tiller extra
versatility-making it more useful in all four
seasons. For those who must cope with snow,
the dozer blade does a surprisingly good job
in moving snow out of the way. For others, the
dozer blade has been a great help in digging a
base
for a small swimming pool or even the pool
itself! But, it's especially useful around the gar-
den and yard.
80
(Photo 6/12) It's easy to relax when you have
the Dozer blade to do the heavy work for you.
