5. Press .
GUID-FB646E44-586B-48D0-AADB-D48C6E76864A
The second half of the bottom bar is lit to indicate that the parameter value is
displayed.
6. Press the up arrow or the down arrow to change the parameter value.
The value ranges from 0–20. When the value is set to 0 seconds the driving
start automatics is disengaged. The default factory value is 4.
7. Press
to save the value.
8. Press
to leave the setting menu and save all changes.
3.8.21 QuickSteer
3.8.21.1 QuickSteer
QuickSteer is a steering system controlled by an electrohydraulic steering valve.
QuickSteer means adjustable steering ratio which gives a great advantage
whenever the driver needs to steer a lot, for example when driving in a small yard
or when doing front loader work. QuickSteer is optional equipment.
QuickSteer has five manually set steering speeds for both forward and reverse
driving. The steering speed setting is dependent on the driving speed so that the
difference between different steering speeds is more substantial at low driving
speeds, whereas at the speed of 20 km/h the steering speed is fixed.
NOTE: When driving on a slippery road with QuickSteer activated, the steering
speed decreases if the tractor is in a four-wheel slide and you try to increase the
speed. Therefore, it is recommended to use the slowest QuickSteer setting when
driving on slippery surfaces.
3. Operation
- 138 -
