GUID-21661BAE-D298-4226-ABD8-9E09755404CC
1. Rear disc stud hole diameter 24 mm
2. Rear tread clearance 275 mm
3. Rear disc center hole diameter 221 mm
Front disc
GUID-4707BB65-556C-421B-8006-288D0B555F42
1. Front disc stud hole diameter 23 mm
2. Front tread clearance 335 mm
3. Front disc center hole diameter 281 mm
6.5.3 Tyre loadings and pressures
NOTE: The permissible wheel load can reduce the maximum permissible axle
load.
Maximum permissible front axle load
• At maximum permissible driving speed, road (kg) 5500
• In working conditions, offroad (kg) 8500
IMPORTANT: On 50 km/h models and when driving at the maximum speed, the
tyre loading is smaller. For information on tyre pressure, see the tyre
manufacturer's catalogue.
6. Technical specifications
- 384 -
