5. Press the light panel on/off button again to switch off the light panel.
The panel can be turned off also by switching off the parking lights. When the
panel is turned off, the working light settings are saved and taken into use
when the panel is turned on again.
NOTE: The rotary beacon light (optional) can be turned on and off from the
light panel independently.
6. Turn the light switch to off position.
3.4.4 Using the cab light
The tractor is equipped with a step light(s) and cab lights.
GUID-9C953E56-E65D-4C8E-8A16-9A2D354A864F
1. Cab light
2. Cab light switch
The cab lights and step light(s) function automatically as follows:
• When the door is opened, both the cab and step lights are lit.
• When the door is closed, the lights go out in 10 seconds.
• If the door is left open, the lights go out in 10 minutes.
The cab light switch has three positions: left, centre and right.
• To turn on the cab lights, push the switch to the right.
Two white cab lights are continuously on but the red LED light is off.
• To turn off the cab lights, push the switch to the centre position.
The two white cab lights and step light(s) are turned on only when the door is
opened. The red LED light is not on.
• To turn on the red panel light, push the switch to the left.
The red LED light is continuously on, and the two white cab lights are turned
on when the door is opened.
3. Operation
- 85 -
