GUID-DDB244F9-DCD5-44E2-9207-1E5BF5566642
1. 370 mm = 1530 kg / 426 mm = 1070 kg
2. 213 mm
3. 129 mm
4. 280 mm
6.14.6.4 Agricultural towing device
NOTE: The loadings are applicable to all tires.
D-value
1)
78.5 kN
Drawbar eye standard ISO 5692-1, ISO 5692-2, ISO 8755, ISO1102
1)
Mathematically established horizontal force
The agricultural towing device is fixed without pick-up hitch
The horizontal distances of the pulling point from the power take-off (PTO) shaft
and the corresponding maximum vertical loadings are pointed out in the following
figure:
6. Technical specifications
- 401 -
