• To sound the horn, push the horn button.
3.5.3 Using the rotary beacon light
Rotary beacon light is an extra equipment.
GUID-6F8BE120-48CF-48FF-AAC3-AF25A59C59B9
1. Button for rotary beacon light
1. Press the button for rotary beacon light to switch the beacon on or off.
When on, the symbol on the button is lit green.
NOTE: The rotary beacon light (optional) can be turned on and off from the
light panel independently.
3.5.4 Using hazard lights
All four turn signals can be switched on to warn of a hazardous situation.
GUID-920AE15C-6FAE-4866-8C28-AC0AD8F28350
1. Hazard lights switch
1. To make all four turn signals blink, press down the symbol side of the switch.
2. To stop the blinking, press down the side of the switch opposite to the
symbol.
NOTE: If the hazard lights are on and the ignition switch is turned to
(OFF) position, the main power stays on until the hazard lights are switched
off.
3. Operation
- 88 -
