Alternator 150 A
Starter motor 4.3 kW
Suction air preheater (engine induction air) 2.1 kW
Fuses
Cab electric centre 36 fuses
The nominal current rating of the fuses is 5–25 A.
Roof electric centre 25 fuses
The nominal current rating of the fuses is 10–30 A.
Main fuse centre 4 fuses
The nominal current rating of the fuses is 25–250 A.
Engine electric centre 12 fuses
The nominal current rating of the fuses is 3–25A.
Electric preheating of engine induction air 250 A
Cab power supply 125 A
Bulbs
Headlights 55 W-H7
Front position (side) lamps 10 W
Rear/brake lights LED
Direction indicators 21 W front / LED rear
Working lights 65 W-H9 / LED
Cab lights LED
Current sockets
Two-pin current socket ISO 4165
Three-pin current socket ISO/TR 12369
Trailer socket ISO 1724
6.10 Power transmission
6.10.1 Power shuttle
Type
Planetary-type gear drives
2 wet multi-disc clutches
Wet multi-disc clutches 1 for forward driving
1 for reverse driving
Clutches operate also as a driving clutch for current
driving direction.
6.10.2 Clutch
Multi-disc clutch operation
Controlled by oil pressure
Activated by pressing the HiShift push button or the
clutch pedal
Disc numbers, forward/reverse driving
9 pcs/9 pcs
Friction area, forward/reverse driving
1 742 cm
2
/1 742 cm
2
6. Technical specifications
- 390 -
