3.13.3.2 Adjusting hydraulic lift link
The hydraulic lift link is connected to rear auxiliary hydraulic valve 1 or 2.
IMPORTANT: When adjusting the hydraulic lift link, make sure that the implement
does not hit the tractor or ground to avoid damages.
GUID-14291FF4-D888-4971-82D4-2070079BE10F
1. Auxiliary hydraulic lever 1
2. Auxiliary hydraulic lever 2
1. Move the linkage to the position where the lift links are free of load.
2. Lift the hydraulic lift link up by pulling the lever of the auxiliary hydraulics
valve 1 or 2.
3. Lower the hydraulic lift link up by pushing the lever of the auxiliary hydraulics
valve 1 or 2.
3.13.4 Adjusting lower links
You can adjust the lower links into fixed or floating position.
